Oil cylinder test console/oil pump test console




Product Feature

1.4-column type machine body is under balanced stress and has pretty appearance.

2.This equipment adopts force sensor, PLC and touch screen to form intelligent operation system. Data can be output through USB interface.

3.Parameters like pressure, displacement, time and count can be set and displayed on the touch screen.

4.Displacement and pressure of auxiliary oil cylinder can be set and displayed on the touch screen.

5.System pressure can reach 32Mpa, and leakage and unstable pressure of tested oil cylinder or pump can be detected and an alarm is given afterwards.

6.It is professionally designed to test two kinds of products, oil cylinder oil pump. In time of testing oil pump, automatic oiling can be realized to ensure high work efficiency.








Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
W
S
FBY-TFC6.3
3000
770
1000
780
580


Specifications
规格
单位/UNIT
FBY-TFC6.3
Theoretical pressure
理论压力
KN
63
Rated oil pressure
额定油压
MPa
16
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

The height of the bed
工作台离地面高度
mm

The size of the bed
工作台尺寸
mm

Rated oil pressure of tested cylinder
被测试缸额定油压
MPa

Driving power
驱动功率
KW

Power
电源
V

Machine tool external dimension-front   back
机床外型尺寸-前 后
mm

Machine tool external dimension-left   right
机床外型尺寸-左 右
mm

Machine tool external dimension-total   height
机床外型尺寸-总高度
mm

Weight
重量(约)
KG
