FBY-TRC30 Series of Auto Tie Rod End Press-fit Plane Hydraulic Press Machine



Product Feature

1.C Shape polar design. The body has been heat processed in high temperature, therefore, it has good rigidity and little transformation.

2.The PLC control is adopted to make sure that process speed, pressure and time can be freely set on screen with main axis precise position and good reliability.

3.The full oil hydraulic systemis adopted to provide remarkable pressure, stable performance, high precision and wide adjusting range.

4.The pressure detecting range can be set to check if the press fitting product is qualified or not. The over-pressure or pressure shortage during press fitting will trigger warning and stop the machine automatically.

5.Safe Design: it adoptsdoublehand operation mode, whilethe emergency stop and slight moving function are well equipped.

6.The upper mould can be moved aside while it’s not working. It’s suitable for installing ball headed rod and other rod style parts.

7.There is a head cylinder under the platform with adjustable heading time. It can serve for material installation and uninstallation.

8.The downward speed of main axis can be set to fast-moving and pressure-increasing mode. The fast-moving mode can improve working efficiency while the mode can be adjusted to improve the press fitting quality for the sake of protecting mould and product.

9.The product offers start button and foot-on button to start circulation.

10.The sealing components adopts NOK in Japan and Dingji Group in Taiwan, while the hydraulic components are famous brands from Taiwan.

11.The product is equippedwith torque detector to test the riveting quality of ball headed components.

12.Failure warning, pre-diagnosis, fault diagnosis function (optional).






Technical Parameters

The specific technical data, Please contact our staff of the company

Specifications
规格
单位/UNIT
FBY-TRC30
Rated oil pressure
主缸额定油压
MPa
15
Theoretical outpute pressure
主缸理论压力
KN
300(30T)
Max stroke
主缸最大行程
mm

Max Opening Height
主缸最大开口高度
mm

Throat depth
喉深
mm

Fast-forward speed
主缸快下速度
mm/s

Working speed
主缸增压工进速度
mm/s

Rturn speed
主缸回程速度
mm/s

Side cylinder work schedule
侧缸工作行程
mm

Under DingGang work schedule
下顶缸工作行程
mm

DingGang work under pressure
下顶缸工作压力
KN

The height of the bed
下顶缸工作压力
mm

The size of the bed
有效工作台尺寸(前后*左右)
mm

The size of die shank hole
模柄尺寸
mm

Motor power
油泵电机功率
Kw

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
机床总重量(约)
Kg

Fuel tank capacity
油箱容量
L
