FBY-MZ Series Automatic stamping press of automobile hub balancing pads



Product Feature

1.It adopts structural design of turntable-type and double stamping heads to ensure compact structure, little space occupation and easy operation.

2.Piston rod adopts mechanical position limitation. Downward stroke is adjustable with high positioning accuracy ±0.02mm.

3.Downward stroke has two kinds of speeds, namely fast movement and work feeding. Fast movement can improve operating efficiency. Th speed of work feeding can be easily adjusted so as toprotect molds and improve product quality.

4.It can realize full automatic operation of feeding, discharging, lubricant adding and detect stamping head cracks or not.

5.It is used for a series of processes like balance pad chamfering, words stamping, rivet stamping and leveling etc. All processes can be clamped for one time to improve processing precision.

6.It is furnished with related protective devices to avoid over-voltage, motor over-current, overload and electric leakage.




Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
W
S
FBY-MZ-10
2000
850
2800
1500
FBY-MZ-10
2100
850
3000
1800


Specifications
规格
单位/UNIT
FBY-MZ-10
FBY-MZ-20
Rated oil pressure
额定油压
MPa
12
15
Theoretical pressure
理论压力
Kn
100
200
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Number of work position
工位数
-

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The height of the bed
工作台距地面高度
mm

The size of the bed
有效工作台尺寸
mm

Weight
机床总重量(约)
Kg
