Your location:Index >> 6-workbench Numerical Control Hydraulic Roller Bur 6-workbench Numerical Control Hydraulic Roller Bur

FBY-M06-XFC05 6-workbench numerical control hydraulic roller burnishing machine


Product Feature
1.With C-type machine body design, this roller burnishing machine adopts HT250 integral casting and has good rigidity, small deformation through high temperature aging treatment.

2.High rigidity riveting head structure, angle-adjustable multiple-shaft positioning abrasion-resistant tungsten steel rolling wheel and filings-removing cooling/filtering system make this machine especially suitable for roller-burnishing of accessory surface. Product roller-burnishing roughness ≤Ra0.8.

3.Rolling-polishing products have wide diameter ranges. Products of different diameters can be rolling-polished by adjusting riveting head opening and adopting different rolling wheels.

4.Adoption of all hydraulic system ensures high pressure, wide pressure adjustment range, stable operating performance and high accuracy.

5.Principal axis adopts variable frequency power head design.Rotary speed of principal axis can be adjusted freely, with wide actuating range.

6.Downward movement stroke has two kinds of speeds, fast stepping and pressurized slow stepping. Fast stepping improves operation efficiency. The speed of pressurized slow stepping can be adjusted freely to protect molds and improve press-fitting quality of products.

7.Adopting PLC control, the machine realizes human-computer interchange through touch screen, thus ensuring easy operation.

8.Multiple-workbench riveting machine covers small area, saves factory construction land, reduces workforce costs.

9.With safety design, the machine adopts double-hand operation and has functions of emergency stop and up-and-down inching.

10.Adopt two circulative starting modes, button and pedal.

11.Infrared safety device (Optional according to customers' demands)







Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
FBY-M06-XFC05
2400
930
240
1450
350
140
930


Specifications
规格
单位/UNIT
FBY-M06-XFC05
Theoretical pressure
理论压力
KN
50
Rated oil pressure
额定油压
MPa
13
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快下速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

Numberof work position
工位数
-

The size of the bed
工作台有效尺寸
mm

The height of the bed
工作台距地面高度
mm

Motor power
油泵电机功率
KW

Riveting Moter Power
旋铆电机功率
KW

Spindle motor speed
主轴转速范围
rpm

Power(3ΦAC,50Hz)
电源(3ФAC,50HZ)
V

Weight
重量
Kg

Oil tank capacity
油箱容量
L
