FBY-2HM Series of Multi-headed Hydraulic Press



Product Feature

1.The C-body design,use small space and easy to operate.

2.Whole body cast,rigid,and stable performance.

3.Rod mechanical limit,under pressure adjustable stroke,positioning accuracy ±0.02mm.

4.Under the pressure of stroke with the fast-forward speed and feeding speed,speed to improve efficiency,feeding Speeds can be adjusted,To protect the mold,lmprove product quality.

5.Double-head,With automatic discharge function,lmprove Work efficiency.

6.Multi-station presses to reduce labor costs,reduce floor space,increase productivity,improve quality,increase efficiency.

7.Mainly used for small and medium-sized sheet metal drawing,blanding, punching,forming,such as the metal shell of the automotive electronics industry,cosmetics and pharmaceutical industry of packaging cans,pens industry of pen-holderand pen cap,the lamp of the lighting industry of lamp holder and lamp-socket,the bearing industry of maintain frame and needle bearing outerring,alkaline manganese,and nickel cadmium battery steel shell levels,micro-motor casing,lock indudtryof door handles and so on.

8.Transfer press processing,generally only one piece of equipment to complete a number of machining processes,these processes include blanking,drawing,punching,flatten bulging,bending,necking,flanging,roling,embossing,and trimming.

9.Infrared protection can be configured(Optional).






Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H1
H2
S
W
W1
FBY-2HM05-05
2100
890
1100
1580
1200


Specifications
规格
单位/ UNIT
BY-2HM05-05
Theoretical pressure
理论压力
KN
50(50T)
Rated oil pressure
额定油压
Mpa
10
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Return speed
回程速度
mm/s

Pressing speed
工进速度
mm/s

Number of work position
工位数
-

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

Motor power
电机功率
Kw

Mold mounting hole
模柄孔径
mm

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg

Fuel tank capacity
油箱容量
L
30
