Your location:Index >> CNC 6-position Tie Rod Riveting Machine CNC 6-position Tie Rod Riveting Machine

FBY-MC06 Series CNC 6-position Tie Rod riveting machine(configured to automatically detect torque)



Product Feature

1.CNC 6-station tie rod end riveting machine is installed with device to test torque automatically. Multi-station workbench design saves the time of clamping products, thus improving production efficiency. Multi-station hydraulic machine can reduce labor cost, minimize floor space, increase output and improve efficiency.

2.Hydraulic machine is installed with pressure sensor to display actual pressure. Pressure testing range can be set to test whether press-fitted products are qualified or not.

3.This machine adopts PLC control. Movement speed, pressure, time and lower pressure position can be set freely on the screen.

4.All hydraulic system ensures high pressure, stable operating performance, high pressure accuracy and large adjustment range.

5.Adjustment and press-fitting of two kinds circulative starting modes, press button and pedal.

6.Operating frequency:2.5S, press-fitting accuracy:±0.02mm.

7.This machine is installed with automatic testing torque meter to set upper/lower limit torque value. When torque value exceeds required range, the machine can give alarming automatically. Toque testing is ±20N•M.

8.Infrared safety device, four-column hydraulic machine and pressure sensor (optional).




Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
FBY-MC06-T25
2125
900
390
1650
180
600
1400


Specifications
规格
单位/ UNIT
FBY-MC06-T25
Theoretical pressure
理论压力
KN
250
Rated oil pressure
额定油压
Mpa
18
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat depth
喉深
mm

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

The size of die shank hole
模柄尺寸
mm

Motor power
电机功率
Kw

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg

Fuel tank capacity
油箱容量
L
