FBY-SM Series of Special press-fitting machine for multi-station motor rotor



Product Feature

1.Multi-station single-column press machine is mainly applied to press-fitting of steering ball studs, bearings and motor rotors etc. in auto parts industry.

2.Adoption of full oil pressure system ensures high pressure, stable operating performance, high pressure precision and large adjustment range.

3.Main shaft has two kinds of speeds, fast forward and pressurized feeding. Fast forward speed improves work efficiency while pressurized feeding speed can be adjusted optionally within certain range so as to improve product press-fitting quality and protect

molds and products.

4.Multi-station single column press machine is equipped with mold base. Mold can be replaced quickly to shorten mold replacement time, reduce labor cost and floor area and increase output and improve efficiency.

5.Inching/automatic functions can be switched mutually. Automatic function can be realized through foot switch.

6.Safety protection induction device for Infrared ray operation (Optional according to customers’ requirements).




Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
W1
FBY-SM06-10MR
1920
890
340
1330
140
410
820
760


Specifications
规格
单位/ UNIT
FBY-SM06-10MR
Theoretical pressure
理论压力
KN
100(10T)
Rated oil pressure
额定油压
Mpa
13
Max stroke
最大行程
mm

Max Opening Height
最大开口高度
mm

Throat depth
喉深
mm

Down speed
快进速度
mm/s

Return speed
回程速度
mm/s

Pressing speed
工进速度
mm/s

Number of work position
工位数
-

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

Motor power
电机功率
Kw

Mold mounting hole
模柄孔径
mm

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg
