FBY-M Series of Six Working Positions Hydraulic Press Machine



Product Feature

1.The C-body design,compact stucture,overall casting make the machine high rigid.

2.The design of six station save time for clamping products and increase productivity.

3.Rod mechanical limit,under pressure stroke adjustable,positioning accuracy ±0.02mm.

4.Safety designed,using both hands to operate,with emergency stop button and jog up and down function.

5.Key and Foot Switch cycle stare mode.Pressure Speed and time can be adjusted.

6.Widely used in parts of the press-fit shape,stretching,bending,punching,stamping,shaft alignment and press-fit etc.

7.Multi-station presses to reduce labor costs,reduce floor space,increase productivity,improve qulity,increase efficiency.

8.Infrared protection can be configured(Optional).

9.Failure warning, pre-diagnosis, fault diagnosis function (optional).






Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
W1
FBY-M06-10
1920
890
340
1330
140
410
820
760
FBY-M06-15
1920
890
340
1330
140
410
820
760


Specifications
规格
单位/ UNIT
FBY-M06-10
FBY-M06-15
Theoretical outpute pressure
理论出力
KN
100(10T)
150(15T)
Rated oil pressure
额定油压
Mpa
13
14
Max stroke
最大行程
mm

Max Opening Height
最大开口高度
mm

Throat depth
喉深
mm

Fast-forward speed
快进速度
mm/s

Return speed
回程速度
mm/s

Feeding speed
工进速度
mm/s

Number of work position
工位数
-

The size of the working table
工作台尺寸
mm

The height of the working table
工作台距地面高度
mm

Power of motor
电机功率
Kw

Mold mounting hole
模柄孔径
mm

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg

Fuel tank capacity
油箱容量
L
