FBY-H Series of Mute the Microseismicity Hydraulic Punching Machine



产品特点

1.C-type single-column design,machine tool bed HT300 casting,after high temperature aging treatment,good rigidity,a small amount of deformation.

2.Professional design,suitable for a variety of sheet punching,molding,stretch,shear machining,bending,stamping,riveting and other processing.

3.Punch in the work cycle,according to the technological requirements can be variable speed,quiet stamping,micro-vibration,For stamping operations on the floors.

4.The opening height is large,the stroke is adjustable,particularly suitable for deep-barrel products punching, molding.

5.The hydraulic system uses a rapid transformation principle,movement speed,high efficiency,energy saving and environmental protection.

6.Punch down,with two speeds,fast-forward and slow forward,fast forward speed is fast and can improve work efficiency;Slow forward speed can be adjusted,to improve the quality of press-fit,protection of mold and products.

7.Security design,using both hands to operate, with emergency stop and jog up and down function.

8.Two of the cycle start-up mode:buttons and pedals.

9.The seal is NOK from Japan and Taiwan tripod base,hydraulic fittings using brand-name products of taiwan.

10.Infrared protection device(according to customer's requirements)




Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
W1
FBY-H25
2040
680
400
1170
210
460
850
790
FBY-H40
2570
720
400
1400
210
700
950
880
FBY-H63
2700
730
400
1800
250
750
1050
970
FBY-H100
2800
730
450
2000
250
870
1100
1000


Specifications
规格
单位/ UNIT
FBY-H25
FBY-H40
FBY-H63
FBY-H100
Theoretical pressure
理论压力
KN
250(25T)
400(40T)
630(63T)
1000(100T)
Rated oil pressure
额定油压
Mpa
19
23
22
22
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

Motor power
电机功率
Kw

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg

Fuel tank capacity
油箱容量
L
