FBY-X Series of Hydraulic Riveting Machine



Product Feature

1.The C-body design,whole body cast and high rigid.

2.Professional design,suitable for various parts of the flange riveting,such as ball,silicone oil clutch. etc.

3.Frequency power head,adjusting speed arbitrary, wide speed range.

4.Safety design,using both hands to operate, with emergency stop button and jog up and down function.

5.Key and Foot Switch two cycle start modes.

6.Can be equipped with a torque detection device to facilitate the detection of spin riveting quality (Ball special purpose machine).

7.Infrared protection can be configured (Optional).








Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
FBY-X05
2100
910
360
900
240
290
650
FBY-X10
2250
1010
320
900
200
385
658
FBY-X05Q
2100
910
360
900
240
290
650
FBY-X10Q
2250
1010
320
900
200
385
658


Specifications
规格
单位/ UNIT
FBY-X05
FBY-X10
FBY-X05Q配扭矩检测
FBY-X10Q配扭矩检测
Theoretical pressure
理论压力
Kn
50(5T)
100(10T)
50(5T)
100(10T)
Rated oil pressure
额定油压
Mpa
10
12
10
12
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台尺寸
mm

Spin riveting motor power
旋铆电机功率
Kw

Spindle motor speed
主轴转速范围
rpm

Motor power
油泵电机功率
Kw

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg

Fuel tank capacity
油箱容量
L
