FBY-XK Series of CNC Hydraulic Riveting Machine



Product Feature

1.The C-body design,whole body cast and high rigid.

2.Professional design,suitable for various parts of the flange riveting, such as ball,silicone oil clutch. etc.

3.Frequency power head,adjusting speed arbitrary, wide speed range.

4.Safety design,using both hands to operate,with emergency stop button and jog up and down function.

5.Adopts PLC and touch screen,easy to operate.

6.Downward movement with the fast and Feeding speed,the fast forward improve work efficiency;feeding speeds can be adjusted to protect the mold,improve product quality.

7.Equipped with a torque detection device to facilitate the detection of spin riveting quality (Ball special purpose machine).

 8.Key and Foot Switch two cycle start modes.




Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
S3
W
W1
FBY-XKC05
1920
720
380
900
200
400
750
790
500


Specifications
规格
单位/ UNIT
FBY-XKC05
Theoretical pressure
理论压力
Kn
50(5T)
Rated oil pressure
额定油压
Mpa
13
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快下速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

Riveting Motor Power
旋铆电机功率
Kw

Spindle motor speed
主轴转速范围
rpm

Power of motor
油泵电机功率
Kw

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg

Fuel tank capacity
油箱容量
L
