FBY-XK Series of Hydraulic Riveting Machine



Product Feature

1.The C-body design, whole body cast and high rigid.

2.Professional design,suitable for various parts of the flange riveting,such as ball,silicone oil clutch etc.

3.Frequency power head,adjusting speed arbitrary,wide speed range.

4.All hydraulic systems,pressure,stable and reliable performance.

5.Safety designed,using both hands to operate,with emergency stop button and jog up and down function.

6.Downward movement with the fast and Feeding speed,the fast forward improve work efficiency;feeding speeds can be adjusted to protect the mold,improve product quality.

7.Key and Foot Switch two cycle start modes.

8.Infrared protection can be configured (Optional).








Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
S3
W
W1
FBY-XK05
1970
720
380
860
200
410
800
790
500


Specifications
规格
单位/ UNIT
FBY-XK05
Theoretical pressure
理论压力
Kn
50(5T)
Rated oil pressure
额定油压
Mpa
13
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快下速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

Riveting Motor Power
旋铆电机功率
Kw

Spindle motor speed
主轴转速范围
rpm

Power of motor
油泵电机功率
Kw

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg

Fuel tank capacity
油箱容量
L
