FBSY-XHC Series of Sevro Hydraulic Riveting Machine



Product Feature

1.With C-type machine body design, machine body is integrally cast to ensure good rigidity, small deformation through high temperature aging treatment.

2.It is specially designed for edge forming, riveting operation for various accessories, for example, auto steering gears and silicone-oil clutches etc.

3.With power head design, principal axis is driven to rotate by serve motor, and can stop at any required position. Rotary speed of principal axis can be adjusted freely, with easy operation and large actuating range.

4.Adoption of all hydraulic system ensures high pressure, stable operating performance,large pressure adjustment range and high accuracy.

5.With safety design and double-hand operation, the machine is furnished with functions of emergency stop and up-and-down inching.

6.Deep-throat type hydraulic riveting machine is appropriate for products with comparatively large external structure.

7.Movable workbench (push cylinder) can be installed to ensure loading and unloading of materials are conducted within safety area outside riveting head in order to guarantee safety of operators.

8.Principal axis has two kinds of speeds, fast stepping and pressurized slow stepping when moving downwards. Fast stepping improves operation efficiency. The speed of pressurized slow stepping can be adjusted freely to protect molds and improve riveting quality of products.

9.Adopt two kinds of circulative starting modes, manual button and pedal.

10.Products within wide diameter range can be riveted. Products of different diameters can be riveted by adjusting the opening of spin riveting head. Replacement of riveting mold is easy.

11.Infrared safety device (Optional upon customers’ requirements).

12.Spin riveting head is furnished with protective cover to ensure safety of operators.

13.Torque testing device can installed on special machine (auto steering gear).






Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
FBSY-XHC03
2160
900
250
930
250
300
800
FBXY-XHC05
2480
900
300
960
250
350
800


Specifications
规格
单位/ UNIT
FBSY-XHC03
FBSY-XHC05
Theoretical pressure
理论压力
Kn
30(3T)
50(5T)
Rated oil pressure
额定油压
Mpa
10
13
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Return speed
回程速度
mm/s

Pressing speed
工进速度
mm/s

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

Motor power
电机功率
Kw

Riveting moter power
旋转电机(伺服电机)
Kw

Spindle motor speed
主轴范围
rpm

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg
