FBS-X series single-column electric servo riveting machine



Product Feature

1.With C-type machine body design, machine body is integrally cast to ensure good rigidity, small deformation through high temperature aging treatment.

2.This machine adopts PLC control. Actuating speed, pressure and time can be freely set within on the touch screen. Upward-moving position of workbench has high precision and good reliability.

3.It is specially designed for edge forming, riveting operation for various precision accessories such as plunger pump sliding boots  and silicone-oil clutches etc.

4.Principal axis adopts variable frequency power head design.Rotary speed of principal axis can be adjusted freely, with easy operation and wide actuating range.

5.Upward movement is driven by servo electric cylinder. Displacement precision reaches 0.005mm.

6.With safety design, the machine adopts double-hand operation and has functions of emergency stop and up-and-down inching.

7.Upward movement of workbenches has two kinds of speeds, fast stepping and pressurized slow stepping. Fast stepping improves operation efficiency. The speed of pressurized slow stepping can be adjusted freely to protect molds and improve press-fitting quality of products.

8.Adopt two circulative starting modes, button and pedal.

9.Riveted products have wide diameter ranges. Products of different diameters can be riveted by adjusting the opening of riveting head.



10.Infrared safety device (Optional according to customers’ demands).




Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
W
FBS-X-03
2000
880
300
885
240
1200


Specifications
规格
单位/ UNIT
FBS-X-03
Theoretical pressure
理论压力
KN
30
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快下速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The height of the bed
工作台距地面高度
mm

The size of the bed
工作台有效尺寸(左右×前后)
mm

Riveting Moter Power
旋铆电机功率
Kw

Spindle motor speed
主轴转速范围
rpm

Power(3ΦAC,50Hz)
电源(3ФAC,50HZ)
KgV

Weight
重量(约)
Kg
