Your location:Index >> Standard Pneumatic Press Machine Standard Pneumatic Press Machine

FBQ-A Series of Standard Pneumatic Press Machine



Product Feature

1.Compressed air as power source, easy to operate.<br/>

2.Adopt microcomputer control,use small space,easy to operate,beautiful appearance.<br/>

3.No hydraulic system noise,can reduce electricity consumption and thus reduce production costs.<br/>

4.Output force adjustment easy,as long as regulate the input air pressure,should be able to achieve the required pressure.<br/>

5.Safety designed,using both hands to operate,with emergency stop and jog up and down function.<br/>

6.Multi-use,for pressing,punching,riveting,assembly, cutting and so on.




Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
H3
H4
H5
H6
H7
H8
FBQ-A200
630
90
230
75
160
15
35
7
15
FBQ-A400
700
90
255
80
180
15
40
7
15
FBQ-A700
730
90
265
85
190
15
50
6
15
FBQ-A1200
850
95
300
105
210
15
50
9
20
FBQ-A2000
1000
115
340
125
240
23.5
50
9
20
型号Model
W
W1
W2
S
S1
S2
B1
B2
D1
FBQ-A200
290
200
258
340
110
140
20
10
Φ35
FBQ-A400
290
200
258
350
110
140
20
10
Φ35
FBQ-A700
330
240
308
380
120
160
20
10
Φ40
FBQ-A1200
400
280
358
430
130
180
23
13
Φ40
FBQ-A2000
420
300
378
480
140
200
23
13
Φ50



Model
规格
单位/ UNIT
FBQ-A200
FBQ-A400
FBQ-A700
FBQ-A1200
FBQ-A2000
Max working height
最大开口高度
mm

Cylinder stroke
气缸行程
mm

Table size
工作台尺寸
mm

Using pressure
使用压力
Mpa

Mold mounting hole
模柄尺寸
mm

Power
电源
V

Using pressure
使用压力
单位/UNIT
理论压力
Theory pressure
理论压力
Theory pressure
理论压力
Theory pressure
理论压力
Theory pressure
理论压力
Theory pressure
0.4
0.4
Mpa
1.29KN(129kgf)
2.89KN(289kgf)
4.58KN(458kgf)

7.71KN(771kgf)

12.05KN(1205kgf)
0.5
0.5
Mpa
1.61KN(161kgf)
3.61KN(361kgf)
5.73KN(573kgf)
9.64KN(964kgf)
15.07KN(1507kgf)
0.6
0.6
Mpa
1.93KN(193kgf)
4.34KN(434kgf)
6.87KN(687kgf)
11.57KN(1157kgf)
18.08KN(1808kgf)
0.7
0.7
Mpa
2.26KN(226kgf)
5.06KN(506kgf)
8.02KN(802kgf)
13.50KN(1350kgf)
21.10KN(2110kgf)
Weight
重量
Kg
