FBY-Z Series of Gas-liquid Mixed Press Machines



Product Feature

1.The-C-body design, use small space and easy to operate.

2.Using the Principle of supercharger,get high speed and large output forces.

3.No hydraulic system noise,can save electricity consumption and thus reduce production costs.

4.Output adjustment as easy as adjusting the air pressure,can achieve the required pressure.

5.Safety design,using both hands to operate,with emergency stop and jog up and down function.

6.Key and foot Switch two cycle start modes.Pressure Speed can be adjusted.

7.Widely used in parts of the press forming, stretching,bending,punching, stamping, shaft alignment and press-fit etc.



Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
W1
FBY-Z01
1750
850
230
620
130
250
500
280
FBY-Z03
1800
850
250
720
140
260
600
400
FBY-Z05
1950
880
300
720
140
290
600
400
FBY-Z10
2100
920
320
930
200
350
700
510
FBY-Z15
2150
920
350
930
200
400
700
640



Specifications
规格
单位/ UNIT
FBY-Z01
FBY-Z03
FBY-Z05
FBY-Z10
FBY-Z15
Max Opening Height
最大开口高度
mm

Total stroke
总行程
mm

Pressure stroke
增压行程
mm

The size of the
working table
工作台尺寸
mm

Pressure
使用压力
Mpa

Mold mounting hole
模柄孔径
mm

Power(3ΦAC,50Hz)
电源规格
V

Using pressure
使用压力
单位UNIT

理论压力
Theory pressure

理论压力
Theory pressure

理论压力
Theory pressure

理论压力
Theory pressure

理论压力
Theory pressure

0.4
-
Mpa
12.5Kn
20Kn
40Kn
62.4Kn
10.2Kn
0.5
-
Mpa
15.5Kn
25Kn
50Kn
78Kn
12.8Kn
0.6
-
Mpa
18.5Kn
30Kn
60Kn
93.6Kn
15.4Kn
0.7
-
Mpa
21.5Kn
35Kn
70Kn
10.92Kn
17.9Kn
