FBY-FC Series of Four-column Hydraulic Machine



Product Feature

1.The machine adopts the four-clumn structure,high guiding precision,electrical system PLC control,reliability,operational safety and convenient.

2.the Cylinder with the overall forged and precision ground under high pressure to make High reliability,good impact resistance.

3.under the pressure of having to fast forward stroke and station two speeds;fast forward speed work Efficiency, feeding speeds can be adjusted to protect the mold,improve product quality.

4.safe design,using both hands,with each trip up and down the jog function.

5.stroke,pressure,speed,can be adjusted,and with a pressure protection.

6.infrared protection device,the next top cylinder(optional class).




Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
W
W1
FBY-FC100A/B
2155
800
500
1500
750
1090
850
FBY-FC200A/B
2050
800
500
1580
800
1425
950
FBY-FC315A/B
2230
800
600
1685
900
1525
1050
FBY-FC500A/B
2580
800
700
1785
1100
1650
1150



Specifications
规格
单位/ UNIT
FBY-FC100A
FBY-FC100B
FBY-FC200A
FBY-FC200B
FBY-FC315A
FBY-FC315B
FBY-FC500A
FBY-FC500B
Theoretical pressure
理论压力
KN
1000
1000
2000
2000
3150
3150
5000
5000
Rated oil pressure
额定油压
Mpa
21
25
25
25
25
25
25
25
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
有效工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

Motor power
电机功率
Kw

Power(3ΦAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg

Fuel tank capacity
油箱容量
L

Max size
工作台面
Mn
