Your location:Index >> Pull Rod Type Four-column Hydraulic Machine Pull Rod Type Four-column Hydraulic Machine

FBY-PFC Series of Pull rod Type Four-column Hydraulic Machine




Product Feature

1.Four columns body structure, good rigidity, stable performance.

2.Rod mechanical limit, under pressure stroke ,speed,times is adjustable , positioning accuracy ±0.02mm.

3.Under the pressure of stroke with the fast-forward speed and feeding speed ,Fast-forward speed to improve efficiency,feeding Speeds can be

adjusted,To protect the mold,lmprove product quality.

4.Mainly used for small and medium-sized sheet metal drawing, blanking, punching.

5.Infrared protection can be configured (Optional).

6.Failure warning, pre-diagnosis, fault diagnosis function (optional).






Technical Parameters

The specific technical data, Please contact our staff of the company
Specifications
规格
单位/ UNIT
FBY-PFC25
Theoretical pressure
理论压力
KN
250
Rated oil pressure
额定油压
Mpa
16
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Down speed
快进速度
mm/s

Pressing speed
回程速度
mm/s

Return speed
工进速度
mm/s

The size of the bed
工作台尺寸(左右×前后)
mm

The height of the bed
工作台距地面高度
mm

The size of die shank hole
电机功率
Kw

Motor power
模柄孔径
mm

Power(3ΦAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg

Fuel tank capacity
油箱容量
L
