FBY-DFC-H Series of CNC Double Press Heads 4-column Hydraulic Machine



Product Feature

1.This machine adopts four-column structure to ensure balanced pressurizing and high guiding accuracy.

2.Electric system adopts PLC control. Stroke, pressure and speed can be set on the touch screen.

3.Double press heads move downwards synchronically and can press-fit two accessories at the same time. And two press heads can test actual

press-fitting force respectively. Pressure testing range can be set to test whether press-fitted products are qualified or not.

4.With safe design, this machine adopts double-hand operation and is furnished with functions of emergency stop and up-and-down inching.

5.It is widely applied to the press-fitting of precision bearings and gears.

6.Infrared safety device, four-column hydraulic machine (optional).




Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
H3
S
W
FBY-DFC01-H
1550
850
250
1265
850
670



Specifications
规格
单位/ UNIT
FBY-DFC01-H
Theoretical pressure
理论压力
KN
10
Rated oil pressure
额定油压
Mpa
4
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台尺寸(左右×前后)
mm

The height of the bed
工作台距地面高度
mm

Motor power
电机功率
Kw

Power(3ΦAC,50Hz)
电源(3ΦAC,50Hz)
V

Weight
重量(约)
Kg
