FBY-MTC10 Series of Movable Table Hydraulic Machine



Product Feature

1.C type body,the body after high temperature aging treatment,good rigidity small deformation.

2.In order to ensure the safety of operator, configuration of the mobile worktable (pushing cylinder) makes the feeding,feeding in the head outside the security zone; for the relatively large size installation and disassembly need space largeworkpiece; pressing precision is equivalent to the traditionalhydraulic machine.

3.Using PLC control, on the screen to set arbitrary movement speed, pressure, time, under the pressure of high position precision, reliable performance.

4.Equipped with hydraulic sensor and pressure sensor, display the actual pressure, can set the pressure detection range, product testing the pressing is qualified, product in the pressing process of undervoltage automatic alarm and shutdown.

5.Hydraulic system pressure stable performance, high precision, large range of adjusting pressure.

6.Safety design of automatic operation and hand operation, with emergency stop and jog up and down function.

7.Spindle down with the fast and boost work into two kinds of speed, the fast forward improve work efficiency, pressure feeding speed can be adjusted in a certain range, improve product assembling quality, protect the mould and products.

8.Using the manual button and the pedal two cycle start modes.

9.The control system adopts imported famous brand products, high-end PLC, touch screen by Siemens, Mitsubishi, valiant and other high-end brands, hydraulic system adopts imported double proportional valve system (see the specific configuration configuration list).

10.The seal using the NOK and Taiwan tripod base.

11.Infrared operation safety induction device (according to customer demand matching).

12.Failure warning, pre-diagnosis, fault diagnosis function (optional).






Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
FBY-MTC10
1975
800
210
1240
200
450
780



Specifications
规格
单位/ UNIT
BY-MTC10
Theoretical pressure
理论压力
KN
100(10T)
Rated oil pressure
额定油压
Mpa
12
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

Push the cylinder stroke
推缸行程
mm

Push the cylinder speed
推缸速度
mm/s

The size of the bed
移动工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

Motor power
油泵电机功率
Kw

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg

Fuel tank capacity
油箱容量
L
