FBY-EC Series of High Precision CNC Single-column Hydraulic Press



Product Feature

1.The C-body design,whole body casting,After high temperature aging treatment,rigid and stable,The deformation is small.

2.PLC control,on the screen can be arbitrary set speed,pressure time,repeated high positioning accuracy,good performance.

3.Equipped with sensors in hydraulic system and pressure sensors,display actual pressure,Pressure detection range can be set,Detection of press-fit products are qualified,Products in the process of pressing,overvoltage and undervoltage will automatically alarm and shutdown.

4.The whole hydraulic system,the pressure is strong,the work performance is stable,The accuracy of the pressure is high,the adjustment range is large.

5.Security design,using both hands to operate,with emergency stop and jog up and down function.

6.Spindle down,with two speeds,fast-forward and slow forward,fast forward speed is fast and can improve work efficiency;Slow forward speed can be adjusted,to improve the quality of press-fit, protection of mold and products.

7.Two of the cycle start-up mode:buttons and pedals.

8.The whole control system is using imported high-end brand-name products,PLC,The touch screen is the use of high-end brands such as Siemens,Mitsubishi,Wei Lun,The hydraulic system is the use of imported dual proportional system valve (Specific configuration,see the configuration list).

9.The seal is NOK from Japan and Taiwan tripod base,hydraulic fittings using brand-name products of taiwan.

10.Infrared protection device(according to customer's requirements).

11.Failure warning, pre-diagnosis, fault diagnosis function (optional)




Technical Parameters

The specific technical data, Please contact our staff of the company


型号Model
H
H1
H2
S
S1
S2
W
FBY-EC01
1890
890
380
780
140
300
630
FBY-EC02
1890
890
380
780
140
300
630
FBY-EC03
1890
890
380
780
140
300
630
FBY-EC05
1970
880
400
800
140
350
640
FBY-EC10
1000
1000
370
970
200
400
775



Specifications
规格
单位/ UNIT
FBY-EC01
FBY-EC02
FBY-EC03
FBY-EC05
FBY-EC10
Rated oil pressure
额定油压
Mpa
4
8
10
10
12
Theoretical pressure
理论压力
KN
10(1T)
20(2T)
30(3T)
50(5T)
100(10T)
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台距地面高度
mm

The height of the bed
有效工作台尺寸(前后*左右)
mm

The size of die shank hole
模柄孔尺寸
mm

Motor power
油泵电机功率
KW

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
机床总重量(约)

Kg


Fuel tank capacity
油箱容量
L
