FBY-KC-P Series of CNC Single-column Hydraulic Press Machine



Product Feature

1.The C-body design, whole body casting,stable performance, use small space and easy to operate.

2.With PLC control,easy programming process control action,positioning accuracy, high precision.

3.Equipped with pressure sensors,displays the actual pressure,pressure range can be set to detect the product is qualified or not.

4.Safety designed,using both hands to operate,with emergency stop button and jog up and down function.

5.Key and Foot switch two cycle start modes.

6.Control mode can change according to customers requirements.

7.With a filling valve,have a high speed.

8.Widely used in parts of the press forming, stretching,bending,punching, stamping, shaft alignment and press-fit etc.

9.lnfrared protection,under cylinder,and Pressure sensor can be configured(Optional).

10.Failure warning, pre-diagnosis, fault diagnosis function (optional).






Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
S3
W
W1
FBY-KP20P
2040
680
340
1170
230
460
850
850
500
FBY-KP35P
2270
810
410
1400
250
550
1020
910
600
FBY-KP20PT
2040
680
340
1170
230
460
850
1000
500
FBY-KP35PT
2270
810
410
1400
250
550
1020
1200
600



Specifications
规格
单位/ UNIT
FBY-KC20P
FBY-KC20PT
FBY-KC35P
FBY-KC35PT
Theoretical pressure
理论压力
KN
200(20T)
200(20T)
350(35T)
350(35T)
Rated oil pressure
额定油压
Mpa
15
15
19.5
19.5
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

The size of die shank hole
模柄孔尺寸
mm

Motor power
电机功率
KW

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量

Kg


Fuel tank capacity
油箱容量
L
