Your location:Index >> CNC Single-column Hydraulic Press CNC Single-column Hydraulic Press

FBY-KC Series of CNC Single-column Hydraulic Press Machine



Product Feature

1.The C-body design, whole body casting,stable performance, use small space and easy to operate.

2.With PLC control,easy programming process control action,positioning accuracy, high precision,positioning accuracy ±0.02mm.

3.Equipped with pressure sensors,displays the actual pressure,pressure range can be set to detect the product is qualified or not.

4.Safety designed,using both hands to operate,with emergency stop button and jog up and down function.

5.Key and Foot switch two cycle start modes.

6.Control mode can change according to customers requirements.

7.Widely used for bearings,gears and other precision press-fit parts.

8.Infrared protection and Pressure sensor can be configured (Optional).

9.Failure warning, pre-diagnosis, fault diagnosis function (optional).




Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
W1
FBY-KC6.3标准型Standard
1800
720
300
760
160
320
720
520
FBY-KC6.3L特殊型
2100
720
450
760
160
320
750
520
FBY-KC15
2030
750
335
1060
200
410
790
640



Specifications
规格
单位/ UNIT
FBY-KC6.3标准型Standard
FBY-KC6.3L特殊型
FBY-KC15
Theoretical pressure
理论压力
KN
63(6.3T)
63(6.3T)
150(15T)
Rated oil pressure
额定油压
Mpa
12.5
12.5
14
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

The size of die shank hole
模柄孔尺寸
mm

Motor power
电机功率
KW

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量

Kg


Fuel tank capacity
油箱容量
L
