FBY-KP Series of Single-column Hydraulic Press Machine



Product Feature

1.The C-body design,whole body casting,rigid and stable.

2.Rod mechanical limit,under pressure adjustable stroke,positioning accuracy ±0.02mm.

3.Pressure head equipped with a pressure sensor,the value of pressure can be displayed.

4.Key and foot switch two cycle start modes. Pressure Speed and time can be adjusted.

5.Safety designed,using both hands to operate ,with emergency stop button and jog up and down function.

6.Downward movement with the fast and feeding speed , the fast forward improve work efficiency; feeding speeds can be adjusted to protect the mold and improve product quality.

7.Widely used in parts of the press forming,stretching,bending,punching stamping,shaft alignment and press-fit etc.

8.Infrared protection can be configured(Optional).



9.Failure warning, pre-diagnosis, fault diagnosis function (optional).


Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
W1
FBY-KS6.3
1850
720
300
600
160
320
670
520
FBY-KS6.3L
2100
720
450
760
160
320
750
520



Specifications
规格
单位/ UNIT
FBY-KS6.3
FBY-KS6.3L
Theoretical pressure
理论压力
KN
63(6.3T)
63(6.3T)
Rated oil pressure
额定油压
Mpa
12.5
12.5
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

The size of die shank hole
模柄孔尺寸
mm

Motor power
电机功率
KW

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量

Kg


Fuel tank capacity
油箱容量
L
