Your location:Index >> Fast Single-column Hydraulic Press Fast Single-column Hydraulic Press

FBY-CP Series of Fast Single-column Hydraulic Press



Product Feature

1.C-type single-column design,machine tool bed HT300 casting,after high temperature aging treatment,good rigidity,a small amount of deformation.

2.Under pressure stroke can be adjusted,high positioning accuracy,and reliability good.

3.The whole hydraulic system,the pressure is strong,the work performance is stable,the stroke of stamping can be arbitrarily adjusted,and the pressure regulating range.

4.Security design,using both hands to operate,with emergency stop and jog up and down function.

5.Professionally design the correction tool for axis and profiles: the press fitting of axis sets, cast of plate material, bending emboss, stretch, power pressing and other artwork.

6.Spindle down,with two speeds,fast-forward and slow forward,fast forward speed is fast and can improve work efficiency;Slow forward speed can be adjusted,to improve the quality of press-fit,protection of mold and products.

7.Two of the cycle start-up mode:buttons and pedals.

8.The seal is NOK from Japan and Taiwan tripod base,hydraulic fittings using brand-name products of taiwan.

9.Infrared protection device (according to customer's requirements).

10.Failure warning, pre-diagnosis, fault diagnosis function (optional).



Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
FBY-CP05
1950
860
370
800
140
350
640
FBY-CP10
2140
920
380
950
200
350
700
FBY-CP15
2220
920
380
1020
200
380
700



Specifications
规格
单位/ UNIT
FBY-CP05
FBY-CP10
FBY-CP15
Rated oil pressure
额定油压
Mpa
9
11.5
14
Theoretical pressure
理论压力
KN
50(5T)
100(10T)
150(15T)
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快下速度
mm/s

Pressing speed
增压工进速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台距地面高度
mm

The height of the bed
有效工作台尺寸(前后*左右)
mm

The size of die shank hole
模柄尺寸
mm

Motor power
油泵电机功率
Kw

Power(3фAC,50Hz)
电源(3ΦAC,50Hz)
V

Weight
机床总重量(约)
Kg

Fuel tank capacity
油箱容量
L
