FBY-E系列 精密分体式单柱液压机



Product Feature

1.With C-type single column design,machine body is integrally cast to ensure good rigidity and small deformation after high temperature aging treatment.

2.Adoption of all hydraulic system ensures high pressure, stable operating performance,high pressure accuracy and large adjustment range.

3.With safety design, the machine adopts full-automatic operation and double-hand operation, and is furnished with functions of emergency stop and up-and-down inching.

4.Principal axis has two kinds of speeds, fast stepping and pressurized slow feeding when moving downwards. Fast stepping improves operation efficiency. The speed of pressurized slow feeding can be adjusted freely so as to improve product press-fitting quality and protect molds and products.

5.Adopt two kinds of circulative starting mode, manual press button and pedal.

6.The control system of the whole machine adopts imported high-end famous brand products. With PLC control, hydraulic system adopts Imported ratio valve.

7.Sealing element adopts Japan NOK and Taiwan DZ.

8.Infrared operation safety protection induction device (Optional according to customers’ demands).

9.Malfunction pre-alarming, pre-diagnose, malfunction diagnose function (optional).

10.Repeated positioning accuracy ±0.02mm.




Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
FBY-E01
1890
890
380
780
140
300
630
FBY-E02
1890
890
380
780
140
300
630
FBY-E03
1890
890
380
780
140
300
630
FBY-E05
1970
880
400
800
140
350
640
FBY-E10
2240
960
440
970
200
400
775



Specifications
规格
单位/ UNIT
FBY-E01
FBY-E02
FBY-E03
FBY-E05
FBY-E10
Rated oil pressure
额定油压
Mpa
4
8
10
10
12
Theoretical pressure
理论压力
KN
10(1T)
20(2T)
30(3T)
50(5T)
100(10T)
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The height of the bed
工作台距地面高度
mm

The size of the bed
有效工作台尺寸(前后*左右)
mm

The size of die shank hole
模柄尺寸
mm

Motor power
油泵电机功率
Kw

Power(3фAC,50Hz)
电源(3ΦAC,50Hz)
V

Weight
机床总重量(约)
Kg

Fuel tank capacity
油箱容量
L
