FBT-KP Series of Integral Single-column Hydraulic Press Machine



1.The design of C type body, little space occupation, convenient operation.

2.Design of high steel frame, welding using high-quality steel, after eliminating the internal stress process.

3.Flexible point, automatic function, convenient installation and debuggingmold products; dynamic, automatic function can be switched with each other,automatically by the button or foot switch operation (optional); and according to the requirement of the product, arbitrary adjustment under the pressure of time.

4.With a filling valve,air travel fast action.

5.Widely used in parts of the press orming,stretching,bending,punching,stamping,shaft alignment and press-fit etc.

6.Infrared protection can be configured (Optional).

7.Failure warning, pre-diagnosis, fault diagnosis function (optional).




Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
FBY-KP50
2500
975
600
1400
250
875
1150
FBY-KP63
2650
730
500
1600
250
870
1100
FBY-KP100
2650
730
500
1800
250
920
1150
FBY-KP500
3380
600
1390
2600
1180
-
2850



Specifications
规格
单位/ UNIT
FBY-KP50
FBY-KP63
FBY-KP100
FBY-KP500
Theoretical pressure
理论压力
KN
500(50T)
630(63T)
100(100T)
5000(500T)
Rated oil pressure
额定油压
Mpa
24
22
22
25
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Return speed
回程速度
mm/s

Pressing speed
工进速度
mm/s

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

The size of die shank hole
模柄尺寸
mm

Motor power
电机功率
Kw

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
机床总重量(约)
Kg

Fuel tank capacity
油箱容量
L
