FBY-KP Series of Integral Single-column Hydraulic Press Machine


Product Feature

1.The-C-body design, use small space and easy to operate.

2.Whole body casting, rigid and stable performance.

3.With a filling valve,have a high speed.

4.Extension working table,placing the installation of the workpiece conveniently.

5.Downward movement with the fast and feeding speed; the fast forward improve work efficiency;feeding speeds can be adjusted to protect the mold,improve product quality.

6.Key and foot switch two cycle start modes.

7.Safety design,using both hands to operate,with emergency stop and jog up and down function.

8.Widely used in parts of the press forming, stretching,bending,punching, stamping, shaft alignment and press-fit etc.

9.lnfrared protection,under cylinder,and Pressure sensor can be configured(Optional).

10.Failure warning, pre-diagnosis, fault diagnosis function (optional).


Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
S3
W
W1
FBY-KP20
2040
680
435
1170
230
460
850
850
500
FBY-KP20T
2040
680
435
1170
230
460
850
1000
500
FBY-KP35
2270
810
530
1400
250
550
1020
910
600
FBY-KP35T
2270
810
530
1400
250
550
1020
1200
600



Specifications
规格
单位/ UNIT
FBY-KP20
FBY-KP20T
FBY-KP35
FBY-KP35T
Theoretical pressure
理论压力
KN
200(20T)
200(20T)
350(35T)
350(35T)
Rated oil pressure
额定油压
Mpa
15
15
19.5
19.5
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

The size of die shank hole
模柄尺寸
mm

Motor power
电机功率
Kw

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg

Fuel tank capacity
油箱容量
L
