FBY-K Series of Integral Single-column Hydraulic Press Machine


Product Feature

1.The-C-body design, use small space and easy to operate.

2.Whole body casting, rigid and stable performance.

3.Rod mechanical limit, under pressure stroke adjustable , positioning accuracy ±0.02mm.

4.Downward movement with the fast and feeding speed; the fast forward improve product uality.

5.Safety design,using both hands to operate,with emergency stop and jog up and down function.

6.Key and foot Switch two cycle start modes.

7.Widely used in parts of the press forming, stretching,bending,punching, stamping, shaft alignment and press-fit etc.

8.stroke,pressure,speed,can adjust.

9.lnfrared protection,under cylinder,and Pressure sensor can be configured(Optional).

10.Failure warning, pre-diagnosis, fault diagnosis function (optional).



Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
S1
S2
W
W1
FBY-K6.3标准型Standard
1800
720
385
760
160
320
720
520
FBY-K6.3L加长型Long
2100
720
535
760
160
320
750
520
FBY-K15
2030
760
420
1060
200
410
790
640
FBY-D15D
2030
760
420
1060
200
410
790
640



Specifications
规格
单位/ UNIT
FBY-K6.3标准型
Standard
FBY-K6.3(L)特殊型
Long
FBY-K15
FBY-K15D
(快速液压机)
Theoretical pressure
理论压力
KN
63(6.3T)
63(6.3T)
150(15T)
150(15T)
Rated oil pressure
额定油压
Mpa
12.5
12.5
14
20
Max stroke
最大行程
mm

Daylight Opening Height
最大开口高度
mm

Throat Depth
喉深
mm

Down speed
快进速度
mm/s

Pressing speed
工进速度
mm/s

Return speed
回程速度
mm/s

The size of the bed
工作台尺寸
mm

The height of the bed
工作台距地面高度
mm

The size of die shank hole
模柄尺寸
mm

Motor power
电机功率
Kw

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量
Kg

Fuel tank capacity
油箱容量
L
