FBSY-FC Series of Four -column Servo Hydraulic Press


Product Feature

1.Equipment body adopts 3-beam 4-column structure with good rigidity and stable performance.

2.Equipment adopts advanced pump control technology, saving 30%-40% energy compared to common pressure machine. Noise does not exceed 70db.

3.Servo motor directly drives gear pump to supply oil, with stable pressure. When moving downwards, principal axis has high repeated positioning accuracy.

4.Weighing sensor is installed to display actual pressure.

5.Downward stroke has two kinds of speed, fast stepping and slow stepping. Fast stepping speed improves operation efficiency. Slow stepping speed can be adjusted freely to protect molds and improve product quality.

6.The equipment has oil temperature testing function. When oil temperature is too high, this equipment will actuate cooler to cool down hydraulic oil so as to ensure stability of equipment.

7.Pressure and displacement of press-fitting can be tested at the same time. When pressure or displacement is not within set range, the machine will give alarming and stop operation automatically.

8.Maintenance cost is low due to its easy control, less accessories.

9.It is mainly applied to various precision punching and cutting.

10.Long time pressure maintaining can be conducted to ensure product quality after press-fitting is finished. 11.Infrared safety device(optional).


Technical Parameters

The specific technical data, Please contact our staff of the company

型号Model
H
H1
H2
S
W
W1
FBSY-FC50
2000
800
400
770
1100
840
FBSY-FC63
2200
800
500
820
1102
840
FBSY-FC100
2500
800
600
780
300
630
FBSY-FC200
2400
800
600
1000
1200
940
FBSY-FC300
2700
800
700
1120
1350
1085
FBSY-FC500
3100
800
800
1320
1505
1240
FBSY-FC650
2800
800
700
1400
1650
1400
FBSY-FC800
3050
800
850
1680
1920
1680
FBSY-FC1200
3500
800
1000
1800
2050
1800

Specifications
规格
单位/UNIT
FBSY-FC50
FBSY-FC63
FBSY-FC100
FBSY-FC200
FBSY-FC300
FBSY-FC500
FBSY-FC650
FBSY-FC800
FBSY-FC1200
Theoretical output pressure
理论出力
Kn
500
630
1000
2000
3000
5000
6500
8000
12000
Precision of pressure
压力精度
Bar

Repeat positioning accuracy
下行重复定位精度
mm

Rated oil pressure
额定油压
Mpa
20
20
25
25
24
25
20
20
20
Back stroke force
回程力
Kn

Max stroke
最大行程
mm

Max Opening Height
最大开口高度
mm

Fast-forward speed
快进速度
mm/s

Return speed
工进速度
mm/s

Feeding speed
回程速度
mm/s

The size of the working table

工作台尺寸
(左右×前后)

mm

Height of the working table
工作台距地面高度
mm

Power of motor
电机功率
Kw

The holding time
保压时间
S

Power(3фAC,50Hz)
电源(3фAC,50Hz)
V

Weight
重量(约)
kg
